Toggle switch
M3-1536S
Size:5.0mm*2.0mm
Operating Force:100gf
Typical Specifications
1. Rating : DC 6V 300mA
2. Contact Resistance : ≤100mΩ
3.Lnsulation Resistance: DC500V 1Minute
4.Operating Temperature Range: －25℃＋80℃
5.Ambient Humidity Used: ≤85%RH
6. Operating Force : 100gf
7. Operating Life : 10,000Cycles
產(chǎn)品規(guī)格書：
